Brand Name：QiCheng
Model：QCTT1750-28M
Place of Origin：Foshan, GuangDong of China
MOQ：1SET
Lead Time：80 Days
Loading Port：Foshan, China
Payment：T/T,L/C, 35% down payment, full payment be done before shipping
Trade Term：FOB or CIF
Installation & Commissioning：YES
Feature
1.Double-station winding and unwinding, automatic precision cutting and joining ensure non-stop working.
2.Floating pendulum roller type tension mechanism, and tension stable and controllable.
3.Automatic actuator for thickness detection and clearance adjustment ensure the coating precision.
4.The matting mechanism is equipped to effectively remove the smooth surface and make the coating even and smooth.
5.Advanced air duct designed, secondary air return device, low noise, high efficiency, stable and uniform temperature.
6.Fully enclosed insulation oven, electric material shuttle design, negative pressure for energy saving.
7.Famous PLC centralized control, easy operation, the working condition and parameters are shown in details.
Basic Information
| Application | Pure paper, non-woven paper, stone paper and so on, ō0.20~0.27mm |
| Width of products | 1700mm ( can be customized) |
| Accuracy of coating | ±0.005mm |
| Tension control | 5-60kg |
| Production speed | 10-150m/Min |
| Heating method | Heat Transfer fluid or burner heating for optional |
| Power | 133KW |
| Packing style | Nude packing or do with customers requirements |
| Shipping containers | 6 containers |
| Services | 1.Chinese language or English 2.Field installation, commissioning and training 3.Field maintenance and repair service 4.Online support 5.Free spare parts |
